Part No. 0110-003079
Page 3 of 3
rev. 1 11-19-13 DSL
NOTE: Check the bolts periodically to make sure they have not loosened. Re-tighten
after the first 500 miles and then again at 1000 miles
IMPORTANT CHECK LIST
Be sure that all brake lines and fuel lines are clear of headers and/or connector
pipes.
All spark plug wires, battery cables, or other electrical components should be clear
of headers and/or connector pipes.
If dipstick tube was removed, make sure it is installed properly and that the
dipstick has been replaced.
Double-check the tightness of all bolts including brackets and accessories.
PARTS LIST
Qty Description
1 Left side header
1 Right side header
2 Header gasket
2 Reducer gasket
32 Bolt, header, flanged, 3/8”-16 x 1”
38 Lock-washer, 3/8
”
6 Hex head cap screw, 3/8 ”-16 x 1-1/4”
6 Nut, hex, 3/8”-16
Weld
Joint
AUTOMATIC TRANSMISSIONS ONLY
Re-form the L-3 tube as needed for
clearance of the bell housing
L-3
Figure 1
