Part # 0110-003015 Rev 2 3-5-13 DSL
IMPORTANT CHECK LIST
Be sure that all brake lines and fuel lines are clear of headers and/or connector pipes.
All spark plug wires, battery cables, or other electrical components should be clear of
headers and/or connector pipes.
If dipstick tube was removed, make sure it is installed properly and that the dipstick has
been replaced.
Double-check the tightness of all bolts including brackets and accessories.
Perform these checks again after the first 1000 miles.
START THE ENGINE
Start the engine and allow it to warm up to operating temperature. Check for any unusual
noises or exhaust leaks. If every thing is OK, stop the engine and tighten all bolts while
the engine is still warm.
NOTE: Check the bolts periodically to make sure they have not loosened. Re-tighten
after the first 500 miles and then again at 1000 miles.
PARTS LIST
D3353-1 & D3353-3 D3353 & D3353-2
Qty. Description Qty. Description
1 Right side header 1 Right side header
1 Left side header 1 Left side header
1 Right side reducer 1 Right side reducer
1 Left side reducer 1 Left side reducer
2 Header flange gasket 2 Header flange gasket
2
2 ½”, 3 bolt collector gasket
2
2 ½”, 3 bolt collector gasket
1 1”, 2 bolt, E.G.R. gasket 1 1”, 2 bolt, E.G.R. gasket
2
9/16”, 2 bolt A.I.R. gasket
6
3/8”-16 x 2 ¼” hex bolts
6 3/8”-16 x 2 ¼” hex bolts 6 3/8”-16 hex nuts
6
3/8”-16 hex nuts
22
3/8” lock-washers
22 3/8” lock-washers 6 5/16”-18 x 1” Flange bolts
6
5/16”-18 x 1” Flange bolts
6
5/16”-18 Hex nuts
6 5/16”-18 Hex nuts 6 5/16” Lock-washer
6
5/16” Lock-washer
1 Sticker (C.A.R.B., E.O., D-57-19)
1 Sticker (C.A.R.B., E.O., D-57-19)
