Part No. 0110-003043
Page 3 of 3
8-15-2011 DSL
All spark plug wires, battery cables, or other electrical components should be clear
of headers and/or connector pipes.
If dipstick tube was removed, make sure it is installed properly and that the
dipstick has been replaced.
Double-check the tightness of all bolts including brackets and accessories.
PARTS LIST
Qty Description
1 Left side header
1 Right side header
1 Y Pipe assembly
2 Header gaskets
12 3/8”-16 x 1” header bolts
12
3/8” lock-washers
4 7/ 16” lock-washers
4
Screw, cap, hex head, 7/16”-14 x 2”
3 1- 1/4” Spacer
1 Sticker (C.A.R.B., E.O., D-57-19)
FIGURE 1
STOCK A.C.
BRACKET
REMOVE
SHADED
AREAS
WARNING: This label is required to
aid in passing the California smog
check program. This label must be
located in an underhood location that
is readily visible.
