BLACK
YELLOW
RED WHITE
Battery
(-)
Battery
(+)
Tach Output
(DO NOT CONNECT TO
NEGATIVE (-) TERMINL OF
THE COIL)
GREEN
Coil (+) or
Ignition Switch
Coil (-)
To Ignition
Switch
Original Ignition
Switch Wire
BLACK
YELLOW
RED WHITE
Battery
(-)
Battery
(+)
GREEN
Coil (+) or
Ignition Switch
Coil (-)
Original
Tach Wire
Tach Output
(DO NOT CONNECT TO
NEGATIVE (-) TERMINL OF
THE COIL)
(FIGURE 1)
NON-HEI SYSTEMS
HEI SYSTEMS
(FIGURE 2)
Page 2 of 4
