PerTronix Ignitor II 92562 - Manual

440 E. Arrow Highway, San Dimas, CA. 91773
909-599-5955 www.pertronix.com
LIMITED WARRANTY
Pertronix, Inc. Warrants to the original Purchaser of its solid-state ignition system (product) that the
Ignitor, magnet assembly and wiring (components) shall be free from defects in material and workmanship for a
period of (30) months from the date of purchase.
If within the period of the foregoing warranty Pertronix finds, after inspection, that the product or any
component thereof is defective, Pertronix will, at its option, repair such products or component or replace them
with identical or similar parts PROVIDED that within such period Purchaser:
1. Promptly Notifies Pertronix, in writing, of such defects.
2. Delivers the defective products product or component to Pertronix (ATTN: Warranty) with proof of purchase
date; and
3. Has installed and used the product in a normal and Proper manner, consistent with Pertronix printed
instructions.
THE FORGOING LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
WHETHER EXPRESSED OR IMPLIED, INCLUDING AND IMPLIED WARRANTY OR MERCHANTABILITY OR
FITNESS FOR A PURPOSE.
THE FURNISHING OF A REPAIR OR REPLACEMENT COMPONENTS SHALL CONSTITUTE THE SOLE
REMEDY OF PURCHASER AND THE SOLE LIABILITY OF PerTronix WHETHER ON WARRANTY, CONTRACT
OR FOR NEGLIGENCE, AND IN NO EVENT WILL PerTronix BE LIABLE FOR MONEY DAMAGES WHETHER
DIRECT OR CONSEQUENTIAL.
12-VOLT NEGATIVE GROUND INSTRUCTIONS
GENERAL INFORMATION
1. See our website (www.pertronix.com) for the latest product information.
2. IMPORTANT: Read all instructions before starting installation.
3. WARNING!!! DO NOT USE WITH SOLID CORE IGNITION WIRES.
4. The Ignitor II ignition can be used in conjunction with most ignition coils rated at 0.45 ohms or
greater.
5. All external resistors must be removed to achieve optimum performance from the Ignitor II ignition
system.
6. The Ignitor II is compatible as a trigger for most electronic boxes.
IGNITOR INSTALLATION
1. PRIOR TO INSTALLATION TURN IGNITION SWITCH OFF OR DISCONNECT THE
BATTERY
2. Remove distributor cap and rotor from distributor. Do not disconnect spark plug wires
from cap.
3. Examine cap and rotor for wear or damage. Replace as needed.
4. Remove the screws retaining the breaker plate and remove the complete breaker plate
assembly from the distributor housing.
5. The Ignitor does not require any modification to the distributor. Therefore the points,
condenser and hardware can be used as backup.
6. Clean all dirt and excess oil from the breaker plate and point cam.
7. Ignitor II Installation:
•
92562; Make sure that the cutout in the Ignitor mounting plate is lined up with the wire
exit hole in the distributor housing. Use the provided screws to secure mounting plate.
• 92542; Ignitor II kit is designed for clockwise and counter clockwise distributor rotation.
The Ignitor adapter plate is marked “C“ for clockwise and “CC” for counter
clockwise and must be installed properly. Determine which direction the
distributor turns and line up the “C” for clockwise or the “CC” for counter
clockwise to the wire exit notch on the distributor housing. (See Illustration).
Secure plate into place using provided hardware.
8. Install magnet sleeve over distributor shaft. Rotate sleeve until a slight locating
position is felt before applying pressure. With sleeve lined up on reluctor, press
down firmly insuring sleeve is fully seated.
9. Note: The air gap is not adjustable.
10. Insert wires through slot/cutout in distributor housing, and pull wire grommet
into place. Make sure wires do not interfere with any moving part.
For Part Numbers: 92542 & 92562
