EN
To Change Channel 6 to a Reversed Channel 2 for Dual Ailerons
or Reversed Channel 2 to Channel 6
Note: All changes made in advanced programming must start with the receiver powered down to
prevent the motor from running unexpectedly.
To safely accomplish advanced programming feature changes, please enlist the use of a helper. One to
hold the aircraft to prevent unintended flyaways, and one to make the changes on the transmitter.
Sticks must be held in this position while the transmitter is on and the receiver is off.
1. Ensure a successful bind was completed
2. Turn transmitter on
3. Move THRO stick to full throttle position
4. Move Control sticks to the corresponding position to change between the available options (see
illustration)
5. While holding this position, plug the battery into the receiver; power receiver
6. The LED on the receiver will go solid and within 5 seconds the LED will flash 3 times quickly,
indicating the option is now changed
7. Disconnect flight pack from receiver
8. Turn transmitter off
Mode 1
THRO/RUDD ELEV/AILE ELEV/RUDD THRO/AILE
Rev. CH2/CH6
1. Full THRO
2. Up ELEV
3. Left AILE
Mode 2
To Change the Brushed Motor to Operate an Optional Brushless Motor ESC or
Brushless to Brushed Motor Control
The AR6400/AR6400L is capable of operating brushless motors with the use of an optional brushless
ESC, please see the illustration below for instructions.
Sticks must be held in this position while the transmitter is on and the receiver is off.
1. Ensure a successful bind was completed
2. Turn transmitter on
3. Move THRO stick to full throttle position (see illustration)
4. Move Control sticks to the corresponding position to change between the available options (see
illustration)
5. While holding this position, plug the battery into the receiver; power receiver
6. The LED on the receiver will go solid and within 5 seconds the LED will flash 3 times quickly,
indicating the option is now changed
7. Disconnect battery from receiver
8. Turn transmitter off
Mode 1
THRO/RUDD ELEV/AILE ELEV/RUDD THRO/AILE
1. Full THRO
2. Left RUDD
Mode 2
Brushed/
Brushless
To Change Channel 5 to X-port or X-port to Channel 5
Note: When X-Port is active, CH5 and CH6 are not available; however, reversed aileron (CH2) is still
available.
Note: All changes made in advanced programming must start with the receiver powered down to
prevent the motor from running unexpectedly.
