EN
The AR6400/AR6400L 6-channel Ultra-Micro receiver with integrated servos, speed control and
X-Port ™ technology is designed for Ultra-Micro aircraft. Featuring DSM2 ™ technology the AR6400/
AR6400L is compatible with all Spektrum ™ , JR ® , E-flite ® and ParkZone ® 2.4GHz DSM2 technology
transmitters including: Spektrum DX7, DX6i, DX5e, Spektrum Module Systems, JR12X, JRX9303,
E-flite LP5DSM, E-flite HP6DSM, E-flite MLP4DSM and ParkZone’s 2.4GHz DSM2 Transmitter.
Note: The AR6400/AR6400L receiver is not compatible with the DX6 park flyer radio system.
Features
• 6-channel Ultra-Micro receiver
• Two integrated linear servos (elevator and rudder)
• Integrated brushed speed control
• Compatible with external brushless speed controls (optional)
• Weighs just 3.9 grams
• Compatible with optional Spektrum Ultra-Micro linear servos; 1.5-gram
(SPMAS2000) 1.7-gram (SPMAS2000L)
• Smart Bind™ technology
• X-Port allows for future expansion
Applications
The AR6400/AR6400L is designed for Ultra-Micro aircraft and is ideal for scratch-built
ultra-micro projects. The AR6400/AR6400L is designed to utilize a single cell LiPo
battery. Two sizes are available, 3.7V 110mAh (EFLB1101S/PKZ1034) and 3.7V 70mAh
(PKZ3001). An integrated brushed speed controller can be used to power a brushed
motor up to 2 amps of continuous current or an optional brushless controller can be
used. An integrated X-Port feature allows for future expansion.
Note: When X-Port is active, CH5 and CH6 are not available; however, reversed aileron
(CH2) is still available.
AR6400 Specifications:
Type: DSM2 Ultra-Micro receiver with integrated brushed speed controller and two linear
servos
Channels: 6 channels or 4 channels plus X-Port
Modulation: DSM2
Dimension (WxLxH): 27.75 x 27.15 x 8.10mm
Weight: 3.9 g
Input Voltage Range: 1-cell LiPo 3.2 to 4.2V
Antenna Length: 31mm
Resolution: 1024
Compatibility: All DSM2 aircraft transmitters
Servos:
Force: 2.8 oz (79 g)
Stroke: 7.4mm
Speed: 0.14 sec
Speed Controller:
Type: Integrated brushed
Max continuous current: 2.0 amps
