Specifications
MAIN UNIT CX-LDV700
TUNER
FM tuning range 87.5 MHz to 108 MHz
FM usable sensitivity (IHF) 13.2 dBf
FM antenna terminals 75 ohms (unbalanced)
AM tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
AM usable sensitivity 350 µV/m
AM antenna Loop antenna
DISC PLAYER
Laser Semiconductor laser (DVD video
discs λ = 650 nm, CDs λ = 780 nm)
Signal-to-noise ratio 90 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
Signal format NTSC color system
S-VIDEO OUT (S1) Y output: 1 Vp-p (75 ohms,
unbalanced)
C output: 0.286 Vp-p
VIDEO OUT Video composite output, 1 Vp-p (75
ohms, unbalanced), one RCA jack
Operating conditions 5°C to 35°C (41°F to 95°F)
GENERAL
Input AUX: 400 mV
Output TO TS-LW700U: Din 8-pin
LINE OUT: 300 mV, 1 kohm
DIGITAL OUT (OPTICAL)
PHONES: 32 ohms or more
Power requirements 120 V AC, 60 Hz
Power consumption 25 W
Standby power consumption ECO ON: 0.7 W
ECO OFF: 9 W
Dimensions (W x H x D) 249 x 92 x 289 mm
(9
7 / 8 x 3 5 / 8 x 11 1 / 2 in.)
Weight 3.6 kg (7 lbs 15 oz)
SUB WOOFER TS-LW700
Input FROM CX-LDV700U: DIN 8-pin
Output FRONT: IMP. 8 ohms
CENTER: IMP. 8 ohms
SURROUND: IMP. 8 ohms
Power output Front:
30 W + 30 W (40 Hz - 20 kHz, THD
less than 1 %, 8 ohms)
37 W + 37 W (1 kHz, THD 10 %, 8
ohms)
Rear (Surround):
30 W + 30 W (40 Hz - 20 kHz, THD
less than 1 %, 8 ohms)
37 W + 37 W (1 kHz, THD 10 %, 8
ohms)
Center:
30 W (40 Hz - 20 kHz, THD less than
1 %, 8 ohms)
37 W (1 kHz, THD 10 %, 8 ohms)
Subwoofer:
55 W (40 Hz - 200 Hz, THD less than
1 %, 6 ohms)
68 W (60 Hz, THD 10 %, 6 ohms)
Speaker type Bass reflex type, (Magnetic shielded)
Speaker unit 160 mm (6 3 / 8 in.)
Frequency response 40 Hz - 200 Hz
Power requirements 120 V AC, 60 Hz
Power consumption 170 W
Dimensions (W x H x D) 220 x 383 x 450 mm
(8
3 / 4 x 15 1 / 8 x 17 3 / 4 in.)
Weight 12 kg (26 lb. 7 oz)
FIVE SURROUND SPEAKERS SYSTEM SX-L700
(Front, surround and center speakers)
Speaker system 1 way (magnetic shielded*)
Speaker units 80 mm (3 1 / 4 in.) cone
Impedance Front: 8 ohms
Surround: 8 ohms
Center: 8 ohms
Dimensions (W x H x D) 100 x 220 x 115 mm
(4 x 8
3 / 4 x 4 5 / 8 in.) (with pedestal)
100 x 110 x 115 mm
(4 x 4
3 / 8 x 4 5 / 8 in.) (without
pedestal)
Weight 0.55 kg (1 lbs 3 oz)
Accessories: Wall mounting screws (5)
Anti-skid patches (9)
* The surround speakers are not magnetic shielded.
Specifications and external appearance are subject to change
without notice.
DOLBY DIGITAL/DOLBY PRO LOGIC
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic" and the double-D symbol are trademarks
of Dobly Laboratories. Confidential unpublished works.
1992-1997 Dolby Laboratories. All rights reserved.
DTS
Manufactured under license from Digital Theater Systems, Inc.
US Pat. No. 5,451,942 and other worldwide patents issued
and pending. “DTS” and “DTS Digital Surround” are
trademarks of Digital Theater Systems, Inc. 1996 Digital
Theater systems, Inc. All rights reserved.
