AT-MCF6xx and AT-MCF12xx Installation Guide
17
Installing the Multichannel Media Converter in a Rack
To install the unit in a 19-inch rack, perform the following steps:
1. Remove all equipment from the shipping package and store the package in
a safe place.
Caution
Do not remove the dust covers from the fiber optic ports on the
multichannel media converter until you are ready to connect the cables.
Dust contamination can adversely impact the operation of the fiber optic
ports.
2. Select a level, secure surface to prepare the media converter.
3. If you purchased an optional redundant power supply for the switch,
install the redundant power supply by following the directions included
with the unit.
Note
Do not remove the back panel covering the expansion slot for the
optional redundant power supply unless you intend to install the unit.
4. Place the mounting bracket over the mounting holes on one side of the
unit.
5. Insert the three screws provided with the unit and tighten with a suitable
screwdriver, as shown in Figure 8.
Figure 8 Installing the Mounting Bracket
