13
Appendix A
Technical Specifications
Table 3 lists the AT-8116 technical specifications.
Table 3: AT-8116 Technical Specifications
Compatibility
IEEE 802.3; IEEE 802.3u (Fast Ethernet Standard)
Electrical
Rating 115 - 240 VAC, 0.5A
Frequency 50 - 60 Hz
Power Consumption- 50W
Connectors
Ethernet Ports 16, RJ45s
RS232 DB-9
Port LEDs
100M Green
ON indicates port is operating at 100Mbps
COLN/FULL DUP Yellow/Green
Yellow Blinking indicates collision/Green ON indicates Full duplex
LINK Green (ON indicates a valid link to software)
ACT Green (Blinking indicates port activity)
General LED
POWER Green
ON indicates normal operation
Learning Table 8K MAC address
Physical 3.5” x 19” x 14.65” (1.5U)
