12
Technical Specifications
Table 6 lists the switch specifications. For more information, refer to Appendix
B of the AT-9006 Ethernet Switch Installation Guide.
Table 6 Technical Specifications
Physical Specifications
Dimensions (H x W x D)
6.48 cm x 42.93 cm x 35.60 cm
(2.55 in x 16.9 in x 14.0 in)
Weight 6.12 kg (13.60 lbs)
Required Ventilation (all sides) 19 cm (7.5 in)
Environmental Specifications
Operating Temperature 0° to 40° C (32° to 104° F)
Storage Temperature -25° to 70° C (-13° to 158° F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude Range up to 3,000 m (9,843 ft)
Power Specifications
Maximum Power Consumption 95 W
AC Input Voltage 100-120/200-240VAC~ 4/2A, 50/60Hz.
Frequency 50/60 Hz
±
3 cycles of nominal input frequency
DC Redundant Power Voltage +3.3 Vdc 13A
+5 Vdc 8A
+12 Vdc 1A
Safety and Electromagnetic Emissions Certifications
Safety: UL 1950 CSA 22.2 No. 950 EN 60950 (TUV)
EMI: FCC Class A EN55022 Class A VCCI Class A
Immunity: EN50082-1 1997 Quality and Reliability:
MTBF > 50,000 hrs MTTR < 1/2 hr DOA < 1%
CE Compliant
