q Refer to Table 6 for the cabling specifications for the fiber optic port

operating in half-duplex mode.

Table 6 100Base-FX Fiber Optic Ports (Half-duplex)

1

1. The total distance of the fiber optic port lengths cannot exceed the limits stated in the table. Each media converter

used inline within a single collision domain reduces the overall segment length by 40 meters (131 feet).

Selecting a Site

Be sure to observe the following guidelines when selecting a site for your
switch.

q Select a site that is dust-free and moisture-free.

q Select a site that will allow you to easily access the data cables and

power cord.

q Make sure the air flow around the switch and through its vents on the

side and back are not restricted.

q For use on a desktop, make sure the desktop is level and secure.

q Use dedicated power circuits or power conditioners to supply reliable

power to the device.

q Keep the twisted pair cabling away from sources of electrical noise,

such as radios, transmitters, power lines, broadband amplifiers,
electrical motor, and fluorescent fixtures.

Number of Media
Converters

Connected Devices

Maximum Operating
Distance

One Media Converter Inline

Switch to switch

372 m (1,221 ft)

Workstation to switch

372 m (1,221 ft)

Switch to Class I repeater

137 m (450 ft)

Switch to Class II repeater

185 m (607 ft)

Two Media Converters
Inline

Switch to switch

332 m (1,089 ft)

Workstation to switch

322 m (1, 089 ft)

Switch to Class I repeater

97 m (318 ft)

Switch to Class II repeater

145 m (476 ft)
