4
Features
q LEDs for unit and port status
q Auto MDI/MDI-X for the twisted pair ports
q Half- or full-duplex operation on the fiber optic port
q Auto-negotiation of the duplex mode on the twisted pair ports
q RJ-45 twisted pair connectors
q FJ, LC, MT, SC, ST, or VF fiber optic connector
q Store and forward Ethernet packet handling
q MAC address table with a capacity of 4,000 addresses
Status LEDs
Table 3 defines the LEDs on the AT-FS713FC/xx and AT-FS717FC/xx Series
Switches.
Table 3 LEDs
LED Color Description
PWR Green The switch is receiving power.
FD Green
OFF
The fiber optic port is operating in full-duplex mode.
The fiber optic port is operating in half-duplex mode.
100M Green
OFF
The twisted pair port is operating at 100 Mbps.
The twisted pair port is operating at 10 Mbps.
LNK/ACT Green
Blinking Green
OFF
The port has established a valid link with the end-node
connected to the port.
Activity is detected on the port.
The port has not established a link with the end-node.
