Technical Specifications
18
Electrical Rating
Input Supply Voltage 3.3 V DC
Minimum Current Rating 1.5A
Maximum Power
Consumption 6W
Fiber Optic Port Specifications
The following tables list the specifications for the 100Base-FX fiber optic port.
Table 5 Fiber Optic Transmitter
Model
Fiber
Type
1
1. MMF = Multimode Fiber / SMF = Single-mode Fiber.
Fiber
Optic
Diameter
Optical
Frequency
Launch Power 2
2. The launch power is measured at one meter from the transmitter.
Maximum Average Minimum
AT-FS211
AT-FS212
AT-FS214
AT-FS215
AT-FS216
AT-FS217 MMF 50/125 1310 nm -14.0 -20.3 -22.5
MMF 62.5/125 1310 nm -14.0 -16.8 -19.0
AT-FS212/1 SMF 9/125 1310 nm -8.0 -11.5 -15.0
AT-FS212/2 SMF 9/125 1310 nm 0.0 -3.0 -5.0
AT-FS212/3 SMF 9/125 1310 nm 0.0 -2.0 -4.0
AT-FS212/4 3
3. The cable must be non-dispersion-shifted, dispersion-shilfted, or non zero-dispersion-shifted single-mode fiber
optic cable.
SMF 9/125 1550 nm 0.0 -1.5 -3.0
