Allied Telesyn
AT-VIEW PLUS
DEVICE MANAGER
•
•
•
3.2.1 System Name
Usually the System Name is set to a unique descriptive name for identifying the device. This is MIB
object sysName.
3.2.2 System Location
Usually System Location is set to information about where the device is installed. This is MIB object
sysLocation.
3.2.3 System Contact
System Contact is set to the name or phone number of a contact person for the device. This is MIB
object sysContact.
3.2.4 System Description
Usually System Description is set to information about the device such as model name, software
release and version. This is MIB object sysDescr.
3.2.5 Status Bar
The status bar is the area at the bottom of the panel window where a brief description of a
highlighted menu option or toolbar button is displayed. The depressed rectangular area at the right
end of the status bar shows the connection state of AT-View Plus Device Manager.
3 Main Window
PN 613-50504-00 Rev D
Page 19 of 119
