Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
Because an Event Index of 0 is invalid and there is no event related to Index 0, no event will
occur even if the rising alarm is triggered.
TRAP Community
Trap Community name.
Event Description
Text string describing the event. By default, "Rising Event for Alarm#idx" is used where
"idx" represents the Alarm index number.
Falling Alarm Event Rule
Configuration for the falling alarm. If you select "rising alarm" for the Startup Alarm Type,
only "Falling Threshold" and "Falling Event Index" can be configured. If there is no Event
entry corresponding to the Event Index, no event will occur.
Falling Threshold
The floor threshold. If the monitored variable falls below this threshold, a falling alarm event
occurs. The default is 2000.
Event Type
The type of action to be taken when the event occurs. Select one of "none" (no action taken),
"SNMP trap" (send an SNMP trap), "log" (record to the log) and "log & SNMP trap" (record
to the log and send an SNMP trap).
Falling Event Index
The index of the RMON Event entry which is triggered when the sampled value falls below
the falling threshold. If you select "rising alarm" for the Start Alarm Type, this defaults to
zero. Because an Event Index of 0 is invalid and there is no event related to Index 0, no event
will occur even if falling alarm is triggered.
TRAP Community
Trap Community name.
Event Description
Text string describing the event. By default, "Falling Event for Alarm#idx" is used where
"idx" represents the Alarm index number.
7.4.4 Edit Button
: edits the selected Alarm entry. Click this button to open a dialog box, specify options, then click
OK. You can also open this dialog box by double-clicking the entry.
7.4.5 Remove Button
: removes the selected Alarm entry.
PN 613-50504-00 Rev D Page 112 of 119
