AT-29xx Series Gigabit Ethernet Adapters Installation Guide
27
Make sure the card is securely seated. See Figure 6.
Figure 6. Inserting the Network Adapter Card
Note
The connector dock in a 32-bit PCI slot is shorter than in a 64-bit PCI
slot. Although the AT-29xx series adapter is designed to fit in either
slot type, when installed in a 32-bit PCI slot, part of the adapter’s
connector edge remains undocked. This is part of normal operation.
Caution
Do not use excessive force when seating the card, because this may
damage the system or the adapter. If the card resists seating,
remove it from the system, realign it, and try again.
