Allied Telesis AT-2971T User Manual
Page 19
AT-29xx Series Gigabit Ethernet Adapters Installation Guide
19
Off
No valid link at 10 Mbps.
100
Green
On
A valid link has been established at 100
Mbps.
Off
No valid link at 100 Mbps.
1000
Green
On
A valid link has been established at 1000
Mbps.
Off
No valid link at 1000 Mbps.
ACT
Green
On
The adapter is receiving or transmitting
data.
Off
The adapter is not receiving or
transmitting data.
Table 3. AT-2971T LEDs (Continued)
LED
Color
State
Description
