Page 22
Chapter 1: Overview
22
Power Supplies and Fan
The switch has two rear power supply slots, which can accommodate the
following combinations of power supplies and fan unit:
Two AT-PWR02 PSU, AC Only power supplies
One AT-PWR02 PSU, AC Only power supply and one AT-FAN01, Fan
Only Module
In order to be operational, the switch MUST have at least one power
supply installed.
Note
For the power requirements, refer to “Power Specifications” on
page 47.
Note
You must power off the AC power to install or remove the
AT-PWR02 AC power supply or the AT-FAN01 fan module. These
modules are not hot swappable.
The AT-FAN01 fan module is shown in Figure 7 and the AT-PWR02 AC
power supply is shown in Figure 8 on page 23.
Figure 7. AT-FAN01, Fan Only Module
1209
AT-FA
N01
Fan M
odule
FAULT
