Chapter 28: Internet Protocol Version 4 Packet Routing
330 Section VII: Routing
Routing Command Example
This section contains an example of the IPv4 routing feature. It illustrates
the sequence of commands to implementing the feature. To make the
example easier to explain, some of the command options are not
mentioned and the default values are used instead.
Note
This example does not apply to the AT-9408LC/SP, AT-9424T/GB,
and AT-9424T/SP switches, which do not support the packet routing
feature. For an example of how to assign an IP address to those
switches, refer to “Non-routing Command Example” on page 334.
This example has the following sections:
ˆ “Creating the VLANs” on page 331
ˆ “Creating the Routing Interfaces” on page 331
ˆ “Adding a Static Route and Default Route” on page 332
ˆ “Adding RIP” on page 333
ˆ “Selecting the Local Interface” on page 333
This example assumes an AT-9448T/SP switch with four local subnets.
Two subnets will reside in their own VLANs and two will share a VLAN.
The table below lists the relevant information.
Table 26. IPv4 Routing Example
Company
Department
VLAN Name VID
Subnet IP
Address
Subnet Mask Ports
a
Sales Sales 4 149.35.67.0 255.255.255.0 U - 1-11
T- 50
Production Production 5 149.35.68.0 255.255.255.0 U - 12-20
T - 50
Engineering
Group 1 Engineering 11 149.35.69.0 255.255.255.0 U - 21 - 40
T - 50
Engineering
Group 2 149.35.70.0 255.255.255.0
a. U - untagged ports; T - tagged ports
