BCM570x • B57UDIAG User’s Guide
page 3
Broadcom Confidential and Proprietary
3. Functions List
Functions: cmd:
User Command Mode commands
upgfrm
Upgrade PXE or Boot Code from a file
dir
Display file directory in NVRAM
setwol Enable/Disable
WOL
setpxe Enable/Disable
PXE
setasf Enable/Disable
ASF
setmba
Enable Multiple Boot Agent
setipmi Enable/Disable
IPMI
nictest
Run a set of Ethernet Adapter Tests
exit
Exit from command mode
device
Show or switch device
version
Display program version
help
Display available commands
dos
Transfer to DOS prompt
reset Reset
chip
cls Clear
screen
asfprg
Program ASF firmware into NVRAM (3 bin files format)
pasf
Program ASF firmware into NVRAM (1 bin files format)
iscsiprg
Upgrade iSCSI Code from a file
pape Program APE firmware into NVRAM
setman Enable/Disable Management Firmware
Dos Prompt commands
-c
Specify adapter to be test and/or modify
-cmd
Enter user command mode
-w
Enable/Disable (value = 1/0) WOL in manufacture mode
-asf
Enable/Disable (value = 1/0) ASF in manufacture mode
-mba
Option to enable/disable MBA protocol
0. Disable
1. Enable
-mbap
Option to select MBA protocol
0. PXE
1. RPL
2. BOOTP
-mbas
Option to select MBA speed
0. auto
1. 10HD
2. 10FD
3. 100HD
4. 100FD
6. 1000FD (fiber)
-firm
The feature is used to execute a field upgrade of bootcode firmware.
The bootcode firmware is programmed into a/the device/s of a
system if there is a match of the PCI DID, VID, SDID & SVID of
firmware and device.
-firmall
Update devices NVRAM based on
