Allied Telesis B57UDIAG User Manual
Page 6
BCM570x • B57UDIAG User’s Guide
page 2
Broadcom Confidential and Proprietary
2. Prerequisites
OS: DOS 6.22
Software: b57udiag.exe.
Input File List: The following files should be found in the same location of the b57diag.
ee57xxyy.yy (TX & RX CPUs Firmware file, xx chip type, yy version number)
eeprom.bin (Serial EEPROM/FLASH config input file)
cpu.bin, cpu05.bin, cpu14a.bin, cpu14b.bin or cpusj.bin (CPU Instruction test)
cpudiag.bin or cpudg05.bin (CPU Accessing test)
flshdiag.bin, flashdg05.bin flashdg 14a.bin, flashdg 14b.bin, flashdgsj.bin,
flahdg5x.bin
ump14a.bin or ump14b.bin
config.sys
himem.sys
