AT-FS705L Fast Ethernet Switch Installation Guide
27
Installing the Switch on a Table or Desktop
To install the switch on a table or desktop, perform the following
procedure:
1. Remove all the items from the packaging and store the packaging
material in a safe place. In the event a problem occurs and you need to
return the unit, please use as much of the original shipping material as
possible.
2. Attach the four self-adhesive rubber feet to the bottom of the switch, as
shown in Figure 3.
Figure 3. Attaching the Rubber Feet
3. Place the switch on a flat and secure surface, leaving ample space
around the switch for ventilation.
4. Proceed to “Cabling the Switch” on page 30 for the cable installation.
1766
AT-FS705L
5 Po rt 10Base-T/100Base-TX
Fast Ether net Switch
POWER
1 2 3 4 5
1 2 3 4 5
AUTO MDI/MDI-X
LINK ACT 100 10 FDX HDX
