Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Printed on: 10/19/00
38 of 44
11 Appendix C DC-2/MC-1 IR-Codes
Function
Hex
Code Shift Functions Hex Code Rec Function
Hex
Code
Off 19 Trigger Off 99 Zone-2: Off 59
On 18 Trigger On 98 Zone-2: On 58
OSD Off 02 Menu Back Off 82 Reserved 42
FrontPanel Off 03 reserved 83 Reserved 43
LIGHT N/A - -
FrontPanel On 04 reserved 84 Reserved 44
OSD On 05 Menu Back On 85 Status Menu 45
Menu Up 01 Fade Front 81 Reserved 41
Done 0A Balance Left 8A Z-2: Bal Left 4A
SPARE 06 SPARE 86 SPARE 46
Select 08 Balance Right 88 Z-2: Bal Right 48
Menu Down 1D Fade Rear 9D Reserved 5D
Mute 15 Full Mute 95 Z-2: Mute 55
Effect + 1A Center Bal/Fad 9A Lock the LOCK 5A
Effect - 1B EQ Off 9B Reserved 5B
Volume + 17 Volume +5dB 97 Z-2: Volume + 57
Volume - 16 Volume –5dB 96 Z-2: Volume - 56
VCR 13 Bass + 93 R/Z-2: VCR 53
DVD 12 Treble + 92 R/Z-2: DVD 52
V-DISC 11 Tilt + 91 R/Z-2: V-DISC 51
TV 10 Loudness On 90 R/Z-2: TV 50
AUX 0F Bass - 8F R/Z-2: AUX 4F
CD 0E Treble - 8E R/Z-2: CD 4E
TUNER 0D Tilt - 8D R/Z-2: TUNER 4D
TAPE 0C Loudness Off 8C R/Z-2: TAPE 4C
Dolby 20 Nightclub A0 Z-2 Vol: -30dB 60
THX 21 Concert Hall A1 Z-2 Vol: -20dB 61
Logic7 22 Church A2 Z-2 Vol: -10dB 62
dts 23 Cathedral A3 Z-2 Vol: +00dB 63
2-Chan On/Off 24 Expansion Ports* A4 Volume: -30dB 64
Party 25 Panorama A5 Volume: -20dB 65
TV Matrix 26 Mono Logic A6 Volume: -10dB 66
Music 27 Music Surround A7 Volume: +00dB 67
SPARE 28 SPARE A8 SPARE 68
SPARE 29 SPARE A9 SPARE 69
SPARE 2A SPARE AA SPARE 6A
SPARE 2B SPARE AB SPARE 6B
SPARE 2C SPARE AC SPARE 6C
SPARE 2D SPARE AD SPARE 6D
SPARE 2E SPARE AE SPARE 6E
SPARE 2F SPARE AF SPARE 6F
null 30 null B0 null 70
