7.3.8 Get System Parameter Values
Request to DC-2/MC-1 for all current system parameter values. DC-2/MC-1 will respond with the “System
Parameter Values Packet”.
7.3.8.1 Command Packet Description
Application Header:
Command
DC_CMD_GET_SYS_PARAM_VALUES 0x1A
Data Count 0 0x00
Application Data:
N/A
7.3.8.2 System Parameter Values Response Packet
Application Header:
Command
DC_RESP_SYS_PARAM_VALUES 0x84
Data Count SYS_PARAM_COUNT nn
Application Data:
Data[0]
sys_param_value[0] nn
Data[1] sys_param_value[1] nn
Data[…] sys_param_value[…] nn
Data[SYS_PARAM_COUNT-1] sys_param_value[SYS_PARAM_COUNT-1] nn
7.3.8.3 Data Description
sys_param_value:
Data Type: Unsigned 8 bit integer Array.
Max: Dependent on the parameter definition.
7.3.9 Get Effect Definition by Id
Request to DC-2/MC-1 for an effect definition. DC-2/MC-1 will respond with “Effect Definition Packet”.
7.3.9.1 Command Packet Description
Application Header:
Command
DC_CMD_GET_EFFECT 0x1B
Data Count 1 0x01
Application Data:
Data[0]
EffectId nn
7.3.9.2 Data Description
EffectId:
Data Type: Unsigned 8 bit integer
Max: Set by the Effect Count in the “Unit Configuration Packet”.
7.3.9.3 Data Validation:
The EffectId must be a valid Effect Id. If it is not the DC-2/MC-1 will respond with a NAK packet and
error code DC_ERR_ INVALID_EFFECT_ID.
7.3.9.4 Effect Definition Response Packet
