Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Printed on: 10/19/00
21 of 44
Application Header:
Command
DC_RESP_EFFECT_PARAM_VALUES 0x87
Data Count 1 + EffectParamCount nn
Application Data:
Data[0]
EffectId nn
Data[1] effect_param_value[0] nn
Data[…] effect_param_value[…] nn
Data[DataCount-1] effect_param_value[EffectParamCount-1] nn
7.3.11.5 Data Description
EffectId:
Data Type: Unsigned 8 bit integer.
Max: Set by the Effect Count in the “Unit Configuration Packet”.
effect_param_value:
Data Type: Unsigned 8 bit integer array.
Max: Dependent on the parameter definition
7.3.12 Get Custom Name
Request to DC-2/MC-1 for an effect definition. DC-2/MC-1 will respond with “Custom Name Packet”.
7.3.12.1 Command Packet Description
Application Header:
Command
DC_CMD_GET_CUST_NAME 0x2B
Data Count 0 0x00
Application Data:
N/A
7.3.12.2 Data Description
N/A
7.3.12.3 Custom Name Response Packet
Application Header:
Command
DC_RESP_CUST_NAME 0x89
Data Count strlen(CustomName) + 1 nn
Application Data:
Data[0]- Data[DataCount-1]
CustomName ch ch ch … 0x00
7.3.12.4 Data Description
CustomName:
Data Type: Null(0x00) terminated ASCII character string.
Max Length: CUSTOM_NAME_LENGTH defined in Appendix E Protocol Constants.
7.3.13 Get Input Name by Id
Request to DC-2/MC-1 for an input name. DC-2/MC-1 will respond with “Input Name Packet”.
7.3.13.1 Command Packet Description
