DC-2/MC-1 Serial Communications Protocol
Printed on: 10/19/00
22 of 44
Application Header:
Command
DC_CMD_GET_INPUT_NAME 0x2D
Data Count 1 0x01
Application Data:
Data[0]
InputId nn
7.3.13.2 Data Description
InputId:
Data Type: Unsigned 8 bit Integer
Max Value: 7
Conversion: Input Id are defined in Appendix D Input Id’s
7.3.13.3 Data Validation:
The InputId must be a valid Input number. If it is not the DC-2/MC-1 will respond with a NAK packet and
error code DC_ERR_ INVALID_INPUT_ID.
7.3.13.4 Input Name Response Packet
Application Header:
Command
DC_RESP_INPUT_NAME 0x8A
Data Count strlen(InputName) + 2 nn
Application Data:
Data[0]
InputId nn
Data[2]- Data[DataCount-1] InputName ch ch ch … 0x00
7.3.13.5 Data Description
InputId:
Data Type: Unsigned 8 bit Integer
Max Value: 7
Conversion: Input Id’s are defined in Appendix D Input Id’s
InputName:
Data Type: Null(0x00) terminated ASCII character string.
Max Length: INPUT_NAME_LENGTH defined in Appendix E Protocol Constants.
7.3.14 Get FPD Control Registers
Request to DC-2/MC-1 for FPD control registers. DC-2/MC-1 will respond with “FPD Control Register
Packet”.
7.3.14.1 Command Packet Description
Application Header:
Command
DC_CMD_GET_FPD_CONTROL 0x29
Data Count 0 0x00
Application Data:
N/A
7.3.14.2 FPD Control Register Response Packet
