English 17
Specifications
Specifications Model: SyncMaster 755DFG
Picture Tube • 17” (43 cm) DynaFlat [16” (40.6 cm) Viewable]
• 90
° Deflection
• Dot pitch: 0.20 mm (H) / 0.14 mm (V)
• Silica coated with anti-electrostatic properties
(TCO: Multilayer coating)
• Medium-short persistence phosphor
Synchronization • Horizontal: 30 kHz to 85 kHz
• Vertical: 50 Hz to 160 Hz
Display Color • Unlimited
Maximum Resolution • 1600 Dots x 1200 Lines
Active Display • Horizon tal: 12.3 ± 0.16 inch (312.0 ± 4 mm)
• Vertical: 9.2 ± 0.16 inch (234.0 ± 4 mm)
Input Signal,
Terminated • Analog: 0.7 Vpp positive at 75 ohms
• Separate Sync.: TTL level, positive or negative
Maximum Pixel Clock • 135 MHz
Video signal • 1.0 Vpp , 75
W
, NTSC/ PAL/ SECAM
Audio signal • 500 mVrms over than 47 k
W
Power Supply • AC 100-240 V ± 10%, 60 Hz / 50 Hz ± 3 Hz
Power Consumption • 100 W maximum
Dimensions/Weight
(WxDxH) • Unit (Without Speakers): 16.53 x 16.81 x 15.04 inch / 37.5 lbs.
(420 x 427 x 382 mm / 17.0 kg) (Without feet)
(With Speakers): 20.19 x 16.81 x 15.04 inch / 39.7 lbs.
(513 x 427 x 382 mm / 18.0 kg)
• Carton (With Speakers): 20.19 x 22.51 x 21.02 inch / 46.3 lbs.
(513 x 572 x 534 mm / 21.0 kg)
Tilt • Min: 4 ° • Max: 11 °
Environmental
Considerations • Operating temperature: 32 ° F to 104 ° F (0 ° C to 40 ° C)
Humidity: 10% to 80%
• Storage temperature:
-4 ° F to 113 ° F (-20 ° C to 45 ° C)
Humidity: 5% to 95%
Design and specifications are subject to chang e without notice.
