APC RAID Subsystem SCSI-SATA II - Manual (Page 84)

- 84 -
· SATA hard drive
Vendor Model
Hitachi Deskstar 7K250, HDS722580VLSA80, 80GB, 7200RPM, SATA, 8M
Hitachi Deskstar 7K80, HDS728080PLA380, 80GB, 7200RPM, SATA-II, 8M
Hitachi Deskstar 7K500, HDS725050KLA360, 500G, 7200RPM, SATA-II, 16M
Hitachi Deskstar 7K80, HDS728040PLA320, 40G, 7200RPM, SATA-II, 2M
Maxtor DiamondMax Plus 9, 6Y080M0, 80G, 7200RPM, SATA, 8M
Maxtor DiamondMax 11, 6H500F0, 500G, 7200RPM, SATA 3.0Gb/s, 16M
Samsung SpinPoint P80, HDSASP0812C, 80GB 7200RPM, SATA, 8M
Seagate Barracuda 7200.7, ST380013AS, 80G, 7200RPM, SATA, 8M
Seagate Barracuda 7200.7, ST380817AS, 80G, 7200RPM, SATA, 8M, NCQ
Seagate Barracuda 7200.8, ST3400832AS, 400G, 7200RPM, SATA, 8M, NCQ
Seagate Barracuda 7200.9, ST3500641AS, 500G, 7200RPM, SATA-II, 16M
Seagate NL35, ST3400633NS, 400G, 7200RPM, SATA 3Gb/s, 16M
Seagate NL35, ST3500641NS, 500G, 7200RPM, SATA 3Gb/s, 16M
Western Digital Caviar SE, WD800JD, 80GB, 7200RPM, SATA, 8M
Western Digital Caviar SE, WD1600JD, 160GB, 7200RPM, SATA, 8M
Western Digital Raptor, WD360GD, 36.7GB, 10000RPM, SATA, 8M
Western Digital Caviar RE2, WD4000YR, 400GB, 7200RPM, SATA, 16M, NCQ
B. Event notifications
· PD/S.M.A.R.T. events
Level Type Description
Info Disk inserted Info: Disk is inserted.
Info Disk removed Info: Disk is removed.
Warning S.M.A.R.T.
threshold exceed
condition Warning: Disk S.M.A.R.T. threshold
exceed condition occurred for attribute of
1.
read error rate
2. spin up time
3. reallocated sector count
4. seek error rate
5. spin up retries
6. calibration retries
Warning S.M.A.R.T.
information Warning: Disk : Failure to get S.M.A.R.T
information
· Physical HW events
Level Type Description
Warning ECC error Warning: Single-bit ECC error is detected.
Error ECC error Error: Multi-bit ECC error is detected.
Info ECC DIMM
Installed Info: ECC Memory is installed.
