Installing the Product

2-7

2-7

Connecting an HDMI cable

Connect the HDMI OUT port of the AV device (Blu-Ray/DVD/Cable/Satellite box) to the [HDMI (DVI) IN] terminal of the monitor
using the HDMI cable.

Press the [SOURCE] button at the front of the monitor or on the remote control to select mode.

You do not need to make a separate audio connection when connecting via HDMI.
