Description of the Appliance
• The cooker hood is designed to extract unpleasant odours from the
kitchen, it will not extract steam.
• The hood is supplied as an extractor unit and can also be used
with a recirculation mode by fitting a charcoal filter.
Extraction mode
• In this mode fumes are extracted to the outside via a hose
connected to the coupling ring. Fig. 1
• In order to obtain the best performance the hose should have a
diameter equal to the outlet hole.
Recirculation mode
• The air is filtered through
a charcoal filter and
returned to the kitchen.
Fig. 2
• You will need an original
charcoal filter for the
recirculation mode. (See
Special Accessories).
Fig. 1
Ø 120 mm
Ø 150 mm
Top
Rear
Coupling ring
Rear
Top
Ø
150 mm
Fig. 2
