SignalOn ® Series
RF Signal Management
* Kit intended for 0 db default MBB modules (-M0 modules)
** Kit intended for 6 db default MBB modules (-M6 modules)
Accessories
O r d e r i n g I n f o r m a t i o n
Description Catalog Number
Cable Management Kits; (includes rack mount cable management rings)
2 brackets, 2 – 2.5" x 5.5" cable rings N-ACMK-01P
4 brackets, 4 – 2.5" x 5.5" cable rings N-ACMK-04P
Chassis extender Brackets for;
2-position chassis, 23" rack EB-17B
8-position chassis, 23" rack EB-35B
20-position chassis, ETSI 21" rack EB-87B
insertion/Withdrawal Tools
BNC insertion tool with 12" handle BT2000-12
BNC insertion tool with 24" handle BT2000-24
F connector insertion tool SC-FG
Terminating Plugs
BNC terminating plug, 75 W ± 1.0% BNC-TP1
BNC high-performance terminating plug, 75 W ± .1% BNC-TP2
F terminating plug, 75 W ± 1.0% CF-TP1
F high-performance terminating plug, 75 W ± .1% CF-TP2
Attenuator Pads
XX dB pads, qty 25 (replace XX with 00 through 26) N-ACC-AP-XX
1-5 dB pads, 5 of each pad value, total qty 25 N-ACC-AP-S1
6-10 dB pads, 5 of each pad value, total qty 25 N-ACC-AP-S2
11-15 dB pads, 5 of each pad value, total qty 25 N-ACC-AP-S3
16-20 dB pads, 5 of each pad value, total qty 25 N-ACC-AP-S4
21-25 dB pads, 5 of each pad value, total qty 25 N-ACC-AP-S5
3,6,9,12,15 dB pads, 5 of each pad value, total qty 25* N-ACC-AP-M0
0,3,9,12,15 dB pads, 5 of each pad value, total qty 25** N-ACC-AP-M6
75 W termination pads, qty 25 N-ACC-TP-75
BNC Terminating Plugs
(BNC TP-1 and TP-2)
F Terminating Plugs
(CF TP-1 and TP-2)
