AT-2973SX, AT-2973T, and AT-2973T/4 NetExtreme II Family Adapters Installation and User’s Guide

119

For Windows Server 2008, Windows Server 2008 R2 or Windows
7 Operating systems, see “Selecting the Advanced Tab in
Windows Server 2008, Windows Server 2008 R2, and Windows 7”
on page 103.

For Windows Operating systems, see “Selecting the Advanced
Tab in Windows Vista” on page 104
.

The Advanced tab is shown in Figure 19 on page 102.

2. From the Property list on the Advanced tab, select Speed & Duplex.

3. From the Value list on the Advanced tab, select one of the following:

10 Mb Full

10 Mb Half

100 Mb Full

100 Mb Half

Auto

The Auto setting is a speed of 1000 Mb in full duplex mode. This is the
default setting for the adapters.

4. Click OK.

5. If prompted to restart your computer, click Yes.

Although it is not necessary to reboot the system for new adapter
properties to take effect, rebooting is recommended to reinitialize all
registers.

6. Verify that the port LEDs are operating correctly. See one of the

following descriptions:

“AT-2973SX Adapter Physical Description” on page 17

“AT-2973T Adapter Physical Description” on page 18

“AT-2973T/4 Adapter Physical Description” on page 21
