TX320 Transmitter
GPS Connector
Power Port: The green connector on the 18133 power cable connects to this port
CS I/O: Used to connect to the CR1000’s CS I/O port via the SC12 cable
RF Out Connector
FIGURE 4-8. TX320 connectors
