Appendix D. Examples of CAN Data Frames and Data Encoding and Decoding
32bit data frame with two 16bit unsigned integer values LSByte first.
Rxed Bit order within bytes
87654321 87654321 87654321 87654321
Rxed Byte order
Byte 1
Byte 2
Byte 3
Byte 4
Values
B
A
Bit order within values
8 1 16 9 8 1
16 9
Value byte order
LSByte
MSByte
LSByte
MSByte
Start bit (parameter 09:) RH ref 32 25
24 17
16 9
8 1
Start bit (parameter 09:) LH ref
1 8
9 16
17 24
25 32
Start bit (parameter 09:) Right Hand reference.
1: SDM-CAN (P118)
1: 0
SDM
Address
2: 1
Time-quanta
3: 5
Tseg1
4: 2
Tseg2
5: 1000
ID
Bits
0..10
6: 0000
ID
Bits
11..23
7: 00
ID
Bits
24..28
8: 2
Rx, unsigned int, LSB 1st
9: 9
Start
Bit
No.
10: 16
No.
of
Bits
11: 2
No.
of
Values
12: 1
Loc [ value_A ]
13: 1.0
Mult
14: 0.0
Offset
Start bit (parameter 09:) Left Hand reference.
2: SDM-CAN (P118)
1: 00
SDM
Address
2: 1
Time-quanta
3: 5
Tseg1
4: 4
Tseg2
5: 1001
ID
Bits
0..10
6: 0000
ID
Bits
11..23
7: 00
ID
Bits
24..28
8: 2
Rx, unsigned int, LSB 1st
9: 24
-- Start
Bit
No.
10: 16
No.
of
Bits
11: 2
No.
of
Values
12: 1
Loc [ value_A ]
13: 1.0
Mult
14: 0.0
Offset
