RAWS-P Remote Automated Weather Station

5.3.3 Troubleshooting

If a problem is suspected, measure the +12 V and Ground terminal on the
CR1000 printed circuit board wiring panel. Acceptable readings are +11 to
+14 Vdc. Use PC200W software to collect the 1-HR data table from the
CR1000 and review the historical record of battery voltage.

5.4 GOES Transmitter

5.4.1 General Description

The High Data Rate GOES Transmitter (pn TX320) shown in FIGURE 5-2
supports one-way communication, via satellite, from a Campbell Scientific
datalogger to a ground receiving station. Satellite telemetry offers a convenient
communication alternative for field stations where phone systems or RF
systems are impractical or rendered unreliable after a tragedy to the local
infrastructure. Data transmission rates of 100, 300, and 1200 bps are
supported. Because clock accuracy is critical for GOES satellite telemetry, the
TX320 includes a robust, TCXO-based real-time clock and a GPS receiver.

The TX320 has two siting requirements for proper operation. The GOES
antenna must have a clear view of the spacecraft. The GOES antenna is
directional and should be aimed at the spacecraft; both elevation and azimuth
are unique to the location of the planet and must be set. A poorly aimed
antenna will cause a drop in signal strength or possibly prevent successful
transmission.

For more information on the TX320 and antenna siting, go to our website at

www.campbellsci.com

, enter the “TX320” in the “Search” box, and go to the

equipment manual. The TX320 manual is also provided on the ResourceDVD
which ships with the RAWS-P.

The spacecraft specific DCP-Setup parameters for the GOES
transmitter must be entered in the CR1000KD menus for the
TX320 to work properly.

NOTE

16
