PS150/CH150 12 V Charging Regulators
3.6 LED Indicator
The green “Charge” LED will flash approximately once a second if all
incoming connections are correct and there is an adequate charging voltage
present.
4. Specifications
4.1 Specifications
(CHARGE - CHARGE terminals)
AC or DC Source:
AC – (18 to 24) VRMS internally
limited to 1.2 ARMS
DC – (16 to 40) Vdc internally limited to
0.85 A DC
(SOLAR - terminals)
Solar Panel or Other DC Source 1 :
15 to 40 Vdc
Maximum Charging Current:
4.0 ADC typical
3.2 ADC to 4.8 ADC depending on
individual DC voltage source
Battery Charging FLOAT Charging: Vbatt(T) =
13.65 – (24 mV)•(T – 25) +
(0.24 mV)•(T – 25) 2
± 1% Accuracy on charging voltage over
–40° to +60°C range
Operational Temperature Range 2 : –40° to +60°C
Power Out (+12 terminals)
Voltage: Unregulated 12 V from Battery
4.65 A solid-state circuit breaker
Quiescent Current
No Charge Source Present: 160 µA at 13.7 Vdc
No Battery Connected: 930 µA at 30 volt input voltage (ac or
dc)
Rated UL Class 2 Power Supply
Physical Specifications
PS150: 10.6 cm (4.2 in) tall, 19.3 cm (7.5 in)
long, 7.6 cm (3 in) wide
CH150: 10.0 cm (3.9 in) tall, 7.5 cm (3 in) long,
3.7 cm (1.5 in) wide
1. Battery voltages below 8.7 V may result in < 3.0 A current limit because of
foldback current limit.
2. VRLA battery manufacturers state that “heat kills batteries” and recommend
operating batteries ≤ 50°C.
