4WFB120, 4WFB350, 4WFB1K 4 Wire Full Bridge Terminal Input Modules
3: Z=X-Y (P35)
;Subtract zero reading from the
1: 1
X Loc [ mVperV ]
;measurement
2: 2
Y Loc [ mVperV_0 ]
3: 3
Z Loc [ Vr ]
4: Z=X*F (P37)
;Change Vr from mV/V to V/V
1: 3
X Loc [ Vr ]
2: 0.001
F
3: 3
Z Loc [ Vr ]
;The following instructions calculate microstrain
5: Z=X*F (P37)
1: 3
X Loc [ Vr ]
2: -2
F
3: 9
Z Loc [ 1_2Vr ]
6: Z=Z+1 (P32)
1: 9
Z Loc [ 1_2Vr ]
7: Z=X/Y (P38)
1: 3
X Loc [ Vr ]
2: 9
Y Loc [ 1_2Vr ]
3: 10
Z Loc [ Vr_1_2Vr ]
8: Z=X*Y (P36)
1: 10
X Loc [ Vr_1_2Vr ]
2: 8
Y Loc [ Mult ]
3: 4
Z Loc [ uStrain ]
;Output Section
;This example outputs an average of the 1 second readings
;once per minute.
9: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 1
Interval (same units as above)
3: 10
Set Output Flag High
10: Set Active Storage Area (P80)
1: 1
Final Storage Area 1
2: 1
Array
ID
;Set Array ID = 1 for measurement data
11: Real Time (P77)
1: 1110
Year,Day,Hour/Minute
12: Average (P71)
1: 1
Reps
2: 4
Loc [ uStrain ]
*Table 2 Program
01: 0.0000 Execution
Interval
(seconds)
8
