Installation, Wiring – Campbell Scientific 255-100 Novalynx Analog Output Evaporation Gauge User Manual
Page 8
255-100 Novalynx Analog Output Evaporation Gauge
NovaLynx Model 255-250 Evaporation Pan Support Platform (Available
by Special Order)
Wood platform for supporting the evaporation pan
Weight:
30 lb (13.6 kg)
Dimensions:
50” x 50” x 10” (127 cm x 127 cm x 25.4 cm)
This can easily be built by using the NovaLynx sketch, or a
wood pallet of these dimensions might be available locally.
NOTE
3. Installation
Please refer to the NovaLynx instruction manual Section 3.
4. Wiring
The evaporation gauge connects to the datalogger as shown in Figure 5.
FIGURE 5. 255-100 Schematic
FIGURE 6. Close-up of Terminal Strip on 255-100
4
