10164-L Sampler Control Cable for use with Isco and Sigma Autosamplers

TABLE 3-4. Datalogger Wiring to Inhibit a

Sigma Sampler Program

Color

Description

CR800

CR850

CR1000

CR3000

CR500

CR510

CR10(X)

CR23X

21X

Purple

Ground

G

Brown

Control Port

Control Port

(C1, C2,…)

Control Port

(C1, C2,…)

Control

Clear

Shield

G

TABLE 3-5. Datalogger Wiring to Inhibit an

Isco Sampler Program

Color

Description

CR800

CR850

CR1000

CR3000

CR500

CR510

CR10(X)

CR23X

21X

Purple

Ground

G

Green

Control Port Control Port

(C1, C2,…)

Control Port

(C1, C2,…)

Control

Clear

Shield

G

Insulate and tuck the unused wires out of the way.

4. Programming

The datalogger is programmed using either CRBasic or Edlog. Dataloggers

that use CRBasic include the CR800, CR850, CR1000, and CR3000.

Dataloggers that use Edlog include the CR10(X), CR510, CR500, CR23X, and

21X.

With this cable, the datalogger can be programmed to:

Trigger the sampler

Sense and record when the sampler has taken a sample

Inhibit the sampler from running its onboard sampling routine

Each of these functions is independent of the others and may be combined as

desired.

NOTE

4
