05103, 05103-45, 05106, and 05305 R.M. Young Wind Monitors
TABLE 7-3. Parameters for Wind Direction
CR10(X),
CR510,
CR200(X)
CR7, 21X,
CR23X
CR800
CR1000
CR5000,
CR3000
Measurement
Range 2500 mV,
slow 5000 mV,
slow/60 Hz 2500 mV,
60 Hz, reverse
excitation 5000 mV,
60 Hz, reverse
excitation
Excitation
Voltage 2500 mV 5000 mV 2500 mV 5000 mV
Multiplier 0.142 0.071 355 355
Offset 0 0 0 0
7.4.3 Wind Vector Processing Instruction
The Wind Vector output instruction is used to process and store mean wind
speed, unit vector mean wind direction, and Standard Deviation of the wind
direction (optional) using the measured wind speed and direction samples.
7.4.4 Example Programs
The following programs measure the Wind Monitor 05103 every 5 seconds,
and store mean wind speed, unit vector mean direction, and standard deviation
of the direction every 60 minutes. Wiring for the examples is given in TABLE
7-4.
TABLE 7-4. Wiring for Example Programs
Color Wire Label CR1000 CR10X
Red WS Signal P1 P1
Black WS Reference G
Green WD Signal SE 1 SE 1
Blue WD Volt Excit EX 1 E1
White WD Reference AG
Clear Shield G
7.4.4.1 CR1000 Example Program
'CR1000
'Declare Variables and Units
Public Batt_Volt
Public WS_ms
Public WindDir
Units Batt_Volt=Volts
Units WS_ms=meters/second
Units WindDir=Degrees
