05103, 05103-45, 05106, and 05305 R.M. Young Wind Monitors
Wind Direction
05103
Wind
Monitor
05103-45
Wind
Monitor-
Alpine
05106
Wind
Monitor-MA
05305
Wind Monitor-AQ
Range 0° to 360° mechanical, 355° electrical (5° open)
Accuracy ±3° ±5° ±3°
Starting Threshold 1.1 m s –1 (2.4 mph) 0.5 m s –1 (1.0 mph)
Distance Constant
(50% recovery)
1.3 m (4.3 ft) 1.2 m (3.9 ft)
Damping Ratio 0.3 0.45
Damped Natural
Wavelength
7.4 m (24.3 ft) 4.9 m (16.1 ft)
Undamped Natural
Wavelength
7.2 m (23.6 ft) 4.4 m (14.4 ft)
Output analog dc voltage from potentiometer—resistance 10 kΩ; linearity 0.25%;
life expectancy 50 million revolutions
Power switched excitation voltage supplied by datalogger
Physical
05103
Wind
Monitor
05103-45
Wind
Monitor-
Alpine
05106
Wind
Monitor-MA
05305
Wind Monitor-AQ
Operating
Temperature Range
–50° to +50°C, assuming non-riming conditions
Overall Height 37 cm (14.6 in) 38 cm (15 in)
Overall Length 55 cm (21.7 in) 65 cm (25.6 in)
Main Housing
Diameter
5 cm (2 in)
Propeller Diameter 18 cm
(7.1 in)
14 cm
(5.5 in)
18 cm
(7.1 in)
20 cm (7.9 in)
Mounting Pipe
Description
34 mm (1.34 in) outer diameter; standard 1.0 in IPS schedule 40
Weight 1.5 kg
(3.2 lb)
1 kg
(2.2 lb)
1.5 kg
(3.2 lb)
1.1 kg (2.5 lb)
The black outer jacket of the cable is Santoprene ® rubber. This
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will support
combustion in air. It is rated as slow burning when tested
according to U.L. 94 H.B. and will pass FMVSS302. Local fire
codes may preclude its use inside buildings.
CAUTION
7
