Thermal Management (cont’d)
Air Dam, 6-‐Slide Cabinet
42U x 600 -‐ 39085-‐X00
For 23.6” (600 mm), 27.6” (700 mm),
45U x 600 -‐ 39085-‐X03
and 31.5” (800 mm) wide cabinets
48U x 600 -‐ 39085-‐X06
Use with Bottom Panel, p.30, and
52U x 600 -‐ 39085-‐X10
Snap-‐In Filler Panel, p.32.
42U x 700 -‐ 39085-‐X11
45U x 700 -‐ 39085-‐X14
48U x 700 -‐ 39085-‐X17
52U x 700 -‐ 39085-‐X21
42U x 800 -‐ 39085-‐X22
45U x 800 -‐ 39085-‐X25
48U x 800 -‐ 39085-‐X28
52U x 800 -‐ 39085-‐X32
Air Dam, 4-‐Slide Cabinet
42U x 600 -‐ 39130-‐X00
For 23.6” (600 mm), 27.6” (700 mm),
45U x 600 -‐ 39130-‐X03
and 31.5” (800 mm) wide cabinets
48U x 600 -‐ 39130-‐X06
Use with Bottom Panel, p.30, and
52U x 600 -‐ 39130–X10
Snap-‐In Filler Panel, p.32.
42U x 700 -‐ 39130-‐X11
45U x 700 -‐ 39130-‐X14
48U x 700 -‐ 39130-‐X17
52U x 700 -‐ 39130-‐X21
42U x 800 -‐ 39130-‐X22
45U x 800 -‐ 39130-‐X25
48U x 800 -‐ 39130-‐X28
52U x 800 -‐ 39130-‐X32
Baying Seal Kit
42U -‐ 39137-‐700
Seals space between cabinets
45U -‐ 39137-‐703
when bayed 24” apart
48U -‐ 39137-‐706
52U -‐ 39137-‐710
X = Color (C=Black, E=Glacier White)
Other Sizes Available.
