Thermal  Management  (cont’d)



42U  x  800    -­‐    39043-­‐X00



42U  x  1000    -­‐    39043-­‐X08



42U  x  1100    -­‐    39043-­‐X12



42U  x  1200    -­‐    39043-­‐X16

Side  Panel  with  Brush  Sealed

45U  x  800    -­‐    39043-­‐X51

Cable  Openings,  4-­‐Slide

45U  x  1000    -­‐    39043-­‐X59

Pair  of  panels

45U  x  1100    -­‐    39043-­‐X63

for  one  side  of  cabinet

45U  x  1200    -­‐    39043-­‐X67

Includes  one  (1)  key

48U  x  800    -­‐    39043-­‐XAC



48U  x  1000    -­‐    39043-­‐XAL



48U  x  1100    -­‐    39043-­‐XAR



   48U  x  1200  -­‐    39043-­‐XAW



52U  x  800    -­‐    39043-­‐XDL



52U  x  1000    -­‐    39043-­‐XDW



52U  x  1100    -­‐    39043-­‐XEC



52U  x  1200    -­‐    39043-­‐XEG















Bottom  Panel  with  Brushes

600  mm  cabinets    -­‐    39132-­‐X00

Seals  bottom  of  cabinet

700  mm  cabinets    -­‐    39132-­‐X01



800  mm  cabinets    -­‐    39132-­‐X02







Airflow  Director

600,  700,  800  mm  cabinets    -­‐    39107-­‐X00

Use  in  conjunction  with

Vertical  Exhaust  Duct







X  =  Color  (C=Black,  E=Glacier  White)

Other  Sizes  Available.
