Cable  Management  (cont’d)

Cable  Lashing  Bracket,  4-­‐Slide  Cabinet

42U    -­‐    39131-­‐X00

One  (1)  full-­‐height  panel

45U    -­‐    39131-­‐X03

Attaches  to  the  cabinet  frame

48U    -­‐    39131-­‐X06



52U    -­‐    39131-­‐X10




Ring  Cable  Manager,  4-­‐Slide  Cabinet

42U  x  600    -­‐    39127-­‐X00

For  23.6”  (600  mm)  wide  cabinets

45U  x  600    -­‐    39127-­‐X03

One  (1)  full-­‐height  section

48U  x  600    -­‐    39127-­‐X06



52U  x  600    -­‐    39127-­‐X10











Ring  Cable  Manager,  4-­‐Slide  Cabinet

42U  x  700    -­‐    39128-­‐X00

For  27.6”  (700  mm)  wide  cabinets

45U  x  700    -­‐    39128-­‐X03

One  (1)  full-­‐height  section

48U  x  700    -­‐    39128-­‐X06



52U  x  700    -­‐    39128-­‐X10

Ring  Cable  Manager,  4-­‐Slide  Cabinet

42U  x  800    -­‐    39129-­‐X00

For  31.5”  (800  mm)  wide  cabinets

45U  x  800    -­‐    39129-­‐X03

One  (1)  full-­‐height  section

48U  x  800    -­‐    39129-­‐X06



52U  x  800    -­‐    39129-­‐X10



Cable  Port  Brush  Kit

Brushes  for  two  (2)  large  cable  knock-­‐outs

25190-­‐001

in  cabinet  top  panel









Front  to  Back  Cable  Manager
For  27.6”  (700  mm)  &  31.5”  (800  mm)  wide  cabinets

39077-­‐X00







X  =  Color  (C=Black,  E=Glacier  White)

Other  heights  available.

39127-XXX 39128-XXX 39129-XXX
