Veneto venti, Install the crossbar

background image

1

Installation Instructions for

Veneto Venti

1.2

LF400_2D100

980VENETVSP

G

P

I

:

ENERAL

RODUCT NFORMATION

This product can mount to either a 4" square electrical box with

round plaster ring or an octagon electrical box.

This product is suitable for indoor dry locations only.

NOTE: This canopy may be installed to sloped
ceilings with

.

MAX 45

° tilt

Suspension

CAUTION - RISK OF FIRE

This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.

Use minimum 90°c supply conductors.

SCREW

ALLEN

WRENCH

Separate the crossbar from the canopy by removing all
four screws with the Allen wrench provided.

Mount the crossbar to the electrical box with the two
#8-32 screws provided.

#8-32 SCREW

CROSSBAR
ASSEMBLY

Install the Crossbar

1B

1A

1

1

2
