Installation Instructions for
Chicago Jazz (Compact Fluorescent)
980CJAZZSCF
GENERAL PRODUCT INFORMATION:
This product is suitable for damp locations.
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Assemble the Fixture
Gently place the glass shade into the center of the
fixture frame until it is rested in position..
Suspension
1A
1
1.0
PF643_CF
GLASS SHADE
Preparing the Canopy
2B
#8-32
SCREW
CROSSBAR
Mount the crossbar assembly to the electrical box with
the two provided #8-32 screws.
2
2
2
2A
Remove the crossbar from the canopy by completely
unscrewing the strain relief.
1
STRAIN RELIEF
CROSSBAR
CANOPY
