Installation Instructions for
Chicago Jazz
980CJAZZS
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Assemble the Fixture
Gently place the glass shade into the center of the
fixture frame until it is rested in position..
Suspension
1A
1
1.0
LF643_2D
GLASS SHADE
GENERAL PRODUCT INFORMATION:
This product is suitable for damp locations.
This product can be dimmed with a standard incandescent dimmer.
Prepare the Canopy
2B
Secure the mounting plate assembly to the electrical box
with the two provided #8-32 screws.
2
2A
1
1
SCREW
ALLEN
WRENCH
Separate the mounting plate from the canopy by
removing all four screws with the Allen wrench
#8-32 SCREW
CROSSBAR
ASSEMBLY
