Mount the fixture – LBL Lighting Scarlett SD User Manual
Page 2
2
NOTE:
The power cord does not support the fixture.
For a casual “lazy cord” look, cut the power cord
several inches longer that the drop height of the
fixture.
Once the desired look is determined, tighten the set screw on
the strain relief.
Mark the cord underneath the strain relief.
2D
CORD
9
2
8
2
9
2E
4"
Leave 6" of the cord behind the canopy for power connections.
Cut the excess cord.
From the end of the cord, strip the insulation 4" using a sharp
knife.
.
Make sure not to nick the inner wires
Strip the end of the wires.
7
10
7
7
11
12
2
2
2
2C
AIRCRAFT
CABLE
4
5
6
7
Feed the aircraft cable through the cable clutch in the canopy.
Pull the aircraft cable up through the canopy to determine the
fixture height.
Cut off the excess aircraft cable leaving enough for fine leveling
later.
Pull the power cord through the canopy to the desired length.
CABLE
CLUTCH
STRAIN RELIEF
6
4
7
POWER CORD
CANOPY
Mount the Fixture
1
Mount the crossbar assembly to the electrical box with the
two provided #8-32 screws.
3A
#8-32
SCREW
CROSSBAR
1
1
