Baybridge 3 light, Install the fixture
1
Installation Instructions for
Baybridge 3 Light
1.1
HS1861_1A
980BAYBR3CH
G
P
I
:
ENERAL
RODUCT NFORMATION
This product can mount to either a 4" square electrical box with
round plaster ring or an octagon electrical box.
This product is suitable for indoor dry locations only.
This product can be dimmed with an electronic dimmer.
Install the Fixture
Remove the cap nut completely from the canopy.
Remove the backplate from canopy.
CAP NUT
CANOPY
BACKPLATE
Chandeliers
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1A
1
1
1B
2
2
